Bơm dầu bôi trơn AMGP-01NS-T1.8 110V/220V, Aryung


Product Description

• The AMGP-01NS/025NS lubrication pump is a resistive and intermittent pump with a measuring valve.

• This pump has a float switch and a pressure switch inside to check the oil shortage and connect the outside terminal on the main machine to monitor the working conditions.

• As the pump is installed feed button switch inside of pump, it is easy to remove the air and to operate by manual.

• This pump is mainly used for machine tools, printing, foods, injection machine, press and various industrial machines.

Specifications
Type 0NS
Discharge Volume 125/150 cc/min
Working Pressure 1.7 Mpa
Pressure Range 0.2~1.7 Mpa
Reservoir Capacity 1.8 L
Viscosity 30~500 cSt
Outlet 1/8″ (Ø6) PT
Net Weight 2.8 kg
Motor Output 15W
Phase Poles 1Ø/2P
Frequency 50/60 Hz
Rated Voltage 220V
Current 1.8/0.8 A



External Dimensions Diagram

A-Ryung Lubrication Pump AMGP-01NS 220V external dimensions diagram



Circuit & Electrical Connections Diagram



A-Ryung Lubrication Pump AMGP-01NS 220V circuit and electrical connections diagram
